Hot Dipped Galvanized Steel Grating with Customizable Sizes for High Load-Bearing Applications

Ampliación de imagen : Hot Dipped Galvanized Steel Grating with Customizable Sizes for High Load-Bearing Applications

Datos del producto:

Nombre de la marca:	Gnee

Pago y Envío Términos:

Cantidad de orden mínima:	2 piezas
Detalles de empaquetado:	Fijar con cinta metálica Embalaje con palet, envoltura exterior con película plástica impermeable Re
Tiempo de entrega:	Enviado en 20 días después del pago.
Capacidad de la fuente:	300000 metros cuadrados/metros cuadrados por mes

Contacto

Hot Dipped Galvanized Steel Grating with Customizable Sizes for High Load-Bearing Applications

descripción

Resaltar:

Hot Dipped Galvanized Steel Grating

Customizable Sizes Bar Grating

High Load-Bearing Metal Grating

Factory Customized Steel Grating Solutions

Steel grating, also known as bar grating or metal grating, is an open grid assembly of metal bars designed to hold heavy loads with minimal weight. The bearing bars, running in one direction, are spaced by rigid attachment to cross bars running perpendicular to them. This versatile product is widely used as floors, mezzanines, stair treads, fencing, trench covers, and maintenance platforms in industrial settings including factories, workshops, motor rooms, trolley channels, heavy loading areas, boiler equipment, and heavy equipment areas.

Product Specifications

Product Name	Steel Bar Grating
Material	Mild Steel (Low Carbon Steel), S235, S275JR, A36, Stainless Steel SS304, SS316, Aluminum 3003, 5052
Surface Treatment	Hot dipped galvanized, polished, or untreated
Bearing Bar (Width x Thickness)	25x3, 25x4, 30x3, 30x4, 30x5, 32x5, 40x5, 50x5, 75x10mm
Bearing Bar Pitch	12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 34.3, 35, 40, 41, 60mm US standard: 1"x3/16", 1¼"x3/16", 1½"x3/16", 1"x¼", 1¼"×¼", 1½"x¼" etc.
Cross Bar Pitch	38, 50, 76, 100, 101.6mm or customized

Standard Grating Specifications

Bearing Bar: 20×3 to 60×5

Bearing Bar Pitch	Cross-bar Pitch	G203/30/100	G253/30/100	G323/30/100	G403/30/100	G205/30/100	G255/30/100
30	100	G203/30/100	G253/30/100	G323/30/100	G403/30/100	G205/30/100	G255/30/100
30	50	G203/30/50	G253/30/50	G323/30/50	G403/30/50	G205/30/50	G255/30/50
40	100	G203/40/100	G253/40/100	G323/40/100	G403/40/100	G205/40/100	G255/40/100
40	50	G203/40/50	G253/40/50	G323/40/50	G403/40/50	G205/40/50	G255/40/50
60	50		G253/60/50	G253/60/50	G403/60/50	G205/60/50	G255/60/50

Applications

Working Platforms
Handrail Infill
Walkways
Bridge Decking
Stair Treads
Transformer Reservoir
Trench Covers
Ceiling Systems
Grating Fence
Sunshade Panels

etiqueta:

heavy duty steel grating,

steel catwalk grating,

stainless steel bar grating
